IGBT SKKT 106B/12E (SEMIKRON)
Non-returnable
BD 32.500
Thyristor/Diode Modules, SKKH SEMIPACK 1 Series, Semikron
Thyristor/Diode configuration
Approvals
UL recognised component
Approvals
UL recognised component
Thyristors - Semikron
A Thyristor is a solid-state semiconductor device with four layers of alternating N and P-type material. They act as bistable switches, conducting when their gate receives a current trigger, and continue to conduct while they are forward biased. Thyristors are synonymous to Silicon-Controlled Rectifier (SCR).
Encapsulated modules with electrically isolated base plate. Suitable for applications such as battery chargers, welders and plating equipment, regulated power supplies and temperature and speed control circuits.
Choose Quantity
Product Details
| Attribute | Value |
|---|---|
| Thyristor Type | SCR Module |
| Maximum Gate Trigger Voltage | 3V |
| Maximum Gate Trigger Current | 150mA |
| Maximum Holding Current | 250mA |
| Rated Average On-State Current | 106A |
| Repetitive Peak Reverse Voltage | 1200V |
| Surge Current Rating | 2.25kA |
| Mounting Type | Panel Mount |
| Package Type | SEMIPACK1 |
| Pin Count | 5 |
| Peak On-State Voltage | 1.65V |
| Repetitive Peak Forward Blocking Voltage | 1200V |
| Repetitive Peak Off-State Current | 20mA |
| Dimensions | 93 x 20 x 29.4mm |
| Height | 29.4mm |
| Width | 20mm |
| Length | 93mm |
| Maximum Operating Temperature | +130 °C |
| Minimum Operating Temperature | -40 °C |
