Thermal Magnetic Circuit Breaker GV2ME06 1.6A, 600VAC
BD 17.600
The GV2ME06 is an enclosed Motor Circuit Breaker with thermal-magnetic trip unit technology. It is DIN rail mountable with vertical and horizontal mounting positions. The addition of an under-voltage trip enables the motor circuit-breaker to be tripped if voltage is lost. The addition of a shunt trip enables remote control of tripping. The control for the enclosed motor circuit-breaker can be locked in the "N/C" position using 3 padlocks.
Choose Quantity
Product Details
- IK04 and IP20 (conforming to IEC 60529) Protection rating
- Screw clamp terminals
- 100kA at 690VAC Breaking capacity (50/60Hz, conforming to IEC 60947-2)
- 1 to 1.6A Thermal protection adjustment range
- 22.5A Magnetic tripping current
- 2.5W Power dissipation per pole
- Pushbutton control
- 25 cycles/h Operating rate
- -20 to 60°C Ambient air temperature range for operation
Applications
Industrial, Motor Drive & Control, Safety
