GEFRAN Relay GQ-25-48-D-1-1
Non-returnable
33.500BD
Out of stock
Zero crossing relay with antiparallel thyristor output is the most used solid state relay in industrial applications. In fact, it can be used for resistive, inductive and capacity loads. “Zero crossing” relay is energised when voltage meets the zero point and disenergised when current meets the zero point, depending on the signal control on the input circuit. This relay has been designed to stand high-value transitory applications . When the relay has to stand high currents for a long period, it is necessary to grant a proper dissipation and an adequate electrical connection between relay terminals and the load. Varistors, fuses, thermostats and fans are available as fittings. Use the relay with an opportune heatsink (see section accessories).
Main features:
• Alternating current solid state relay
• Zero crossing switching
• Copper/semiconductor coupling technology
• 15, 25, 50 and 90Arms nominal current
• Non-repetitive voltage: up to 1600Vp
• Nominal Voltage: up to 600 Vac
• Control voltage : 3...32Vcc and 20...260Vac/Vcc with connector
• Isolation ((input-output) 4000Vrms
• Red LED drive active signal
• Internal MOV (option)
Product Details
Main applications
• Packaging Machinery
• Thermoforming
• Plastic extrusion lines
• Industrial ovens and furnaces
• Control application with high switching speed
