PIC16F886 (Flash-Based 8-Bit CMOS Microcontroller)

Name: PIC16F886 (Flash-Based 8-Bit CMOS Microcontroller)
SKU: PIC/16F/886
Price: 5.0 BHD
Availability: InStock

BD 5.000

PIC16F886 is a microcontroller good for experimenting and developing applications because it has high flash memory rewrite cycle. Also there are a lot of tutorials and support available online. The controller has 16KBytes flash memory which is enough for many applications. Along with 24 programmable Input/output pins which are developed to handle 20mA current (direct LED driving capability) the system can interface many peripherals easily. With Watchdog timer to reset under error automatically the controller can be used to develop applications of permanent installation.

Applications

Hobbyist projects
Display units
Development board for learners
Analog signal measuring and manipulations
Embedded systems like coffee machine, vending machine
Motor control systems

Choose Quantity

+ Add to Cart

Product Details

PIC16F886 Features

CPU	8-bit
Total pins	28
Programmable pins	24
Communication Interface	SPI Serial Interface(7,14,15,16 PINS) [Can be used for programming this controller] UART Interface(17,18 PINS) [Can be used for programming this controller] Two-wire Serial Interface or I2C(14,15 PINS) [Can be used to connect sensors and LCDs] ICSP or In-Circuit Serial Programming Interface (27,28 Pins) [Can be used for programming this controller]
ADC Feature	11channels of 10-bit resolution
Timer Feature	One 8-bit counter, Two 16-bit counter
Analog Comparators	2
PWM channels	4
External Oscillator	Up to 20MHz
Internal Oscillator	31KHz-8MHz Internal R-C Oscillator featured with: Factory calibrated to ±1% Software selectable frequency range of 8 MHz to 31 kHz Software tunable Crystal fail detect for critical applications Clock mode switching during operation for power savings
Program memory / Flash memory	16Kbytes[100000 write/erase cycles]
CPU Speed	1MIPS @ 1MHz
RAM	368Bytes
EEPROM	256Bytes
Watchdog Timer	Programmable Watchdog Timer with separate on-chip oscillator
Power Save Modes	Available
Operating Voltage	2.0V to 5.5V
Maximum current to any I/O pin	IN :25mA OUT : 25mA
Operating Temperature	-40°C to +125°C
