Cooling Fan 24VDC, 3.2W, 3250rpm (92x92x25.4mm)
BD 23.500
DC Fan Sintec-Sleeve Bearing 24V 3.2W 3250RPM 60.03CFM 39dB Flange Mount
Key Features
- Material: fibreglass- reinforced plastic. Impeller PA, housing PBT.
- Fully integrated electronic commutation.
- Protected against reverse polarity and locking.
- Connection via single strands AWG 24, TR 64. Bared and tin-plated.
- Air exhaust over struts. Direction of rotation counter-clockwise, seen on rotor.
- Mass: 100 g.
- 92 x 92 x 25 mm
- Air Flow cfm: 60.0
Choose Quantity
Product Details
Technical Attributes
| Description | Value | |
|---|---|---|
| Base/Housing Material | Polybutylene Terephthalate | |
| Lead Finish | Tin | |
| Operating Temperature | -20 to 70 °C | |
| Power Rating | 3.2000 W | |
| Product Dimensions | 92 x 92 x 25.4 mm | |
| Product Length | 92 mm | |
| Termination | Leads | |
| Voltage Rating | 24 V |
