220VAC 2000w Motor Speed Control Module
Non-returnable
BD 7.500
Out of stock
Product details of 2000W PWM AC Motor Speed Control Module Dimmer Speed Regulator 50-220V Adjustable Voltage Regulator
- Input supply voltage: 110V ~ 220V AC
- The output voltage:50V-220V(Output voltage < = Input supply voltage)
- The maximum output power: 2000W; The maximum output current :25A
- Item size: 1.85*1.38*1 inches; Net weight: 1.76 ounces
- Operation environment temperature:-20'C-40'C;High efficiency,high torque,low heat generating
This controller uses novel bi-directional high-power SCR. It can be very convenient adjust the current up to 25A, and solve the over current problem of the heating wire resistance is too small in the case of cooling causing good.
The output voltage is adjusted anywhere between 50V-220V for use with electrical appliances. It can use to such as electric stove, water heater tune thermal, lighting dimmer, small motor speed, electric iron thermostat, and achieve dimming, thermostats, pressure regulator effect.
100% brand new and high quality.
Input supply voltage: 110V ~ 250V AC
The output voltage:50V-250V
The maximum output power: 2000W
The maximum output current :25A The voltage regulating range:50V-250V AC
Product Details
Specifications of PWM Variable Speed Motor Controller:
- The voltage is 50-220V.
- The current is 25A.
- Power is 2000W
- Its Size is 52*47*27mm/2*1.85*1in Operation
- Environment Temperature is between -20℃-40℃
Features of SCR Controlled Voltage Regulator:
- This PWM Electronic Speed Controller uses high power SCR which is bi-directional.
- Its output voltages are adjustable so we can adjust anywhere between 50V to 220V for the electrical appliances.
- It is good if we adjust the current up to 25A. By this method, we can solve the current problem of the heating wire resistance.
- We can adjust the PWM motor speed with it so it can be used to such as electric stove, water heater tune thermal.
- It is also used in such as small motor speed, electric iron thermostat.
- It uses such as achieve dimming, thermostats, and also as pressure regulator effect.
