LKP1AF-24V Power Relay, 24VDC, 10A
BD 5.000
Power Relay, SPST-NO, 24 VDC, 10 A, LK-P Series, Through Hole, DC
FEATURES
1. High inrush current capability
- Operating load capability: inrush 100 A, steady 5 A
- UL, CSA, TV-5
2. High insulation resistance between contact and coil
- Creepage distance and clearances between contact and coil: Min. 6 mm .236 inch (In compliance with IEC60065)
- Surge withstand voltage between contact and coil: 10,000 V
3. Popular terminal pitch in AV equipment field mm inch
4. Space-saving slim type Base area: Width 11 × Length 24 mm Width .433 × Length .945 inch
5. Conforms to the various safety standards UL, CSA, VDE, TÜV, SEMKO approved
