Magnet Space Tester, Magnetic Field Detector
Non-returnable
BD 13.500
AXT02 AXIOMET non-contact magnetic field tester
APPLICATIONS
1) Checking the operation of solenoid valves in pneumatic and hydraulic control devices.
2) Checking relays with solenoids and solenoid valves in all types of vehicles and devices.
3) Checking solenoids when repairing oil burners. The test diode lights up immediately and without the need to touch the metal thanks to the control of the magnetic field, e.g. a live coil in the solenoid valve. The test diode lights up when it detects the presence of all kinds of magnetic fields - AC, DC and
permanent magnets .
TAKING MEASUREMENTS
1) Press the TEST button and bring the tester tip close to the magnetic field.
2) When the measuring tip is placed against the magnetic field, the blue LED on the tip turns on.
3) There is no need to remove the element from the device in order to check it - the electromagnet can be checked even through the protective housing.
4) There is no need to turn off the device for checking.
5) Occasionally, foreign magnetic fields from nearby equipment may cause the test LED to light up momentarily. After applying the sensor to the activated solenoid, the test diode will light up continuously.
6) Press and hold the black button to turn on the backlight, releasing the button will turn off the backlight.
APPLICATIONS
1) Checking the operation of solenoid valves in pneumatic and hydraulic control devices.
2) Checking relays with solenoids and solenoid valves in all types of vehicles and devices.
3) Checking solenoids when repairing oil burners. The test diode lights up immediately and without the need to touch the metal thanks to the control of the magnetic field, e.g. a live coil in the solenoid valve. The test diode lights up when it detects the presence of all kinds of magnetic fields - AC, DC and
permanent magnets .
TAKING MEASUREMENTS
1) Press the TEST button and bring the tester tip close to the magnetic field.
2) When the measuring tip is placed against the magnetic field, the blue LED on the tip turns on.
3) There is no need to remove the element from the device in order to check it - the electromagnet can be checked even through the protective housing.
4) There is no need to turn off the device for checking.
5) Occasionally, foreign magnetic fields from nearby equipment may cause the test LED to light up momentarily. After applying the sensor to the activated solenoid, the test diode will light up continuously.
6) Press and hold the black button to turn on the backlight, releasing the button will turn off the backlight.
Choose Quantity
Product Details
SPECIFICATION
Manufacturer AXIOMET
Tester type non-contact magnetic field detector
Pollution degree 2
Dimensions 160 x 20mm
Weight 48g
Power source 2 1.5V LR03 (AAA) batteries
Range of detected magnetic field 63/98/401/810
Manufacturer AXIOMET
Tester type non-contact magnetic field detector
Pollution degree 2
Dimensions 160 x 20mm
Weight 48g
Power source 2 1.5V LR03 (AAA) batteries
Range of detected magnetic field 63/98/401/810
