Power supply 15.2W, 24V

MODEL

DR-15-24

OUTPUT

DC VOLTAGE

24V

CURRENT RANGE

0 ~ 0.63A

RATED CURRENT

0.63A

RATED POWER

15.2W

RIPPLE & NOISE

150mVp-p

VOLTAGE ADJ. RANGE

21.6 ~ 26.4V

VOLTAGE TOLERANCE

1.0%

LINE REGULATION

1.0%

LOAD REGULATION

1.0%

SETUP, RISE TIME

1000ms, 50ms/230VAC 1000ms, 50ms/115VAC at full load

HOLD UP TIME

70ms/230VAC 16ms/115VAC at full load

INPUT

VOLTAGE RANGE

85 ~ 264VAC 120 ~ 370VDC

FREQUENCY RANGE

47 ~ 63Hz

POWER FACTOR

EFFICIENCY

77%

84%

83.5%

85%

AC CURRENT

0.88A/115VAC 0.48A/230VAC

INRUSH CURRENT

COLD START 35A/115VAC 65A/230VAC

LEAKAGE CURRENT

PROTECTION

OVER LOAD

NOTE.5

105 ~ 160% rated output power

Protection type : Constant current limiting, recovers automatically after fault condition is removed

OVER VOLTAGE

5.75 ~ 6.75V

13.8 ~ 16.2V

17.25 ~ 20.25V

27.6 ~ 32.4V

Protection type : Shut off o/p voltage, clamping by zener diode

OTHERS

MTBF

1172.3K hrs min. MIL-HDBK-217F (25 )

DIMENSION

25*93*56mm (W*H*D)

PACKING

0.1Kg; 140pcs/15Kg/0.92CUFT
