Transformer 6VA 230VAC 0.15A
Non-returnable
BD 6.500
Out of stock
Features
- Primary 117/234 VAC, 50/60 Hz.
- All units have dual secondaries except 266LA25 (C.T. secondary only). If you only require
- a single primary & secondary check out our more economical 166 Series.
- Secondaries can be used as; a center tapped secondary, parallel connected or used
- individually (except 266LA25).
- Units are designed for use with all windings engaged.
- Open style.
- Minimum 6" long leads.
- Dual bobbin design - no electrostatic shield required.
- We use Class B insulation (130 degrees, C) for extra protection - UL listed as a Class A
- (105 degree, C) design
- Hi-Pot test of 2,000V RMS.
- UL listed (# E207860) Type 3AH
- CSA certified (209651)
Product Details
Product Technical Specifications
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| Mounting | Flange Mount |
| Transformer Type | Filament Transformer |
| Primary Configuration | Dual |
| Secondary Configuration | Dual |
| Primary Side Connection | Parallel|Series |
| Secondary Side Current (mA) | 300|150 |
| Primary Side Voltage (V) | 117|234 |
| Secondary Side Voltage (V) | 6|12 |
| High Potential | 2000Vrms |
| Power Rating | 1.8VA |
| Lead Style | Wire Lead |
| Number of Terminals | 8 |
| Product Length (mm) | 52.32 |
| Product Height (mm) | 31.75 |
| Product Depth (mm) | 30.99 |
