IC 74283 (4-bit binary adder)
BD 2.500
These are Priority Encoder. They provide priority decoding of the inputs to ensure that only the highest order data line is encoded. Both devices have data inputs and outputs which are active at the low logic level. The LS147 encodes nine data lines to four-line(8-4-2-1) BCD. The implied decimal zero condition does not require an input condition because zero is encoded when all nine data lines are at a high logic level.
These full adders perform the addition of two 4-bit binary numbers. The sum (∑) outputs are provided for each bit and the resultant carry (C4) is obtained from the fourth bit. These adders feature full internal look ahead across all four bits. This provides the system designer with partial lookahead performance at the economy and reduced package count of a ripple-carry implementation. The adder logic, including the carry, is implemented in its true form meaning that the end-around carry can be accomplished without the need for logic or level inversion.
Choose Quantity
Product Details
Features
■ Full-carry look-ahead across the four bits
■ Systems achieve partial look-ahead performance with the economy of ripple carry
■ Typical add times
Two 8-bit words 25 ns
Two 16-bit words 45 ns
■ Typical power dissipation per 4-bit adder 95 mW
