Network Wall Box, 1x RJ45 Female Surface plate
2.500BD
This ethernet LAN WAN networking Faceplate Wall Plate can used in home, office, commercial and industrial buildings to cleanly attach telecommunication networking cables (i.e cat6) etc. to a junction box, surface mount box, or a mud ring mounted in the drywall of a building.
T568A and T568B are the two color codes used for wiring eight-position RJ45 modular plugs. Both are allowed under the ANSI/TIA/EIA wiring standards. The only difference between the two color codes is that the orange and green pairs are interchanged.
T568A wiring pattern is recognized as the preferred wiring pattern for this standard because it provides backward compatibility to both one pair and two pair USOC wiring schemes.
The T568B standard matches the older ATA&T 258A color code and is/was(?) the most widely used wiring scheme. It is also permitted by the ANSI/TIA/EIA standard, but it provides only a single pair backward compatibility to the USOC wiring scheme.
The U.S. Government requires the use of the preferred T568A standard for wiring done under federal contracts.
T568A and T568B are the two color codes used for wiring eight-position RJ45 modular plugs. Both are allowed under the ANSI/TIA/EIA wiring standards. The only difference between the two color codes is that the orange and green pairs are interchanged.
T568A wiring pattern is recognized as the preferred wiring pattern for this standard because it provides backward compatibility to both one pair and two pair USOC wiring schemes.
The T568B standard matches the older ATA&T 258A color code and is/was(?) the most widely used wiring scheme. It is also permitted by the ANSI/TIA/EIA standard, but it provides only a single pair backward compatibility to the USOC wiring scheme.
The U.S. Government requires the use of the preferred T568A standard for wiring done under federal contracts.
Choose Quantity
Product Details
Specification:
- Wiring diagram for both the 568A and 568B are on the keystone jack
- Color: White
Package Content:
- 5x Ethernet Network Cat6 Faceplate Wall Plate - Dual (2 Port) RJ45 Connector Socket Wiring Plug Jack Decorative Face Cover Outlet Mount Panel Female to Female
