BT151 (THYRISTOR 500V, 7.5A)
BD 1.300
Phase Control Thyristors, WeEn Semiconductors
Thyristors - WeEn Semiconductors
A Thyristor is a solid-state semiconductor device with four layers of alternating N and P-type material. They act as bistable switches, conducting when their gate receives a current trigger, and continue to conduct while they are forward biased. Thyristors are synonymous to Silicon-Controlled Rectifier (SCR).
Choose Quantity
Product Details
Specifications
| Attribute | Value |
|---|---|
| Rated Average On-State Current | 7.5A |
| Thyristor Type | SCR |
| Package Type | TO-220AB |
| Repetitive Peak Reverse Voltage | 800V |
| Surge Current Rating | 132A |
| Mounting Type | Through Hole |
| Maximum Gate Trigger Current | 15mA |
| Maximum Gate Trigger Voltage | 1.5V |
| Maximum Holding Current | 20mA |
| Pin Count | 3 |
| Length | 10.3mm |
| Width | 4.7mm |
| Height | 9.4mm |
| Dimensions | 10.3 x 4.7 x 9.4mm |
| Repetitive Peak Off-State Current | 0.5mA |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| Peak On-State Voltage | 1.75V |
| Repetitive Peak Forward Blocking Voltage | 800V |
