MPU-9265 (GY 9250) 9-axis 9-DOF Attitude Gyro Magnetometer Accelerator Sensor Module
Non-returnable
10.000BD
A high-quality MPU-9265 (GY 9250) 9-axis 9-DOF attitude gyro magnetometer accelerator sensor module, perfect for various sensor module applications, including sensing, detecting, and more. This sensor module features a reliable performance and a durable design, making it ideal for sensing and detecting.
Choose Quantity
Product Details
Features:
1.Gyroscope Features
The triple-axis MEMS gyroscope in the MPU-9250 includes a wide range of features:
Digital-output X-, Y-, and Z-Axis angular rate sensors (gyroscopes) with a user-programmable fullscale range of ±250, ±500, ±1000, and ±2000°/sec and integrated 16-bit ADCs
Digitally-programmable low-pass filter
Gyroscope operating current: 3.2mA
Sleep mode current: 8µA
Factory calibrated sensitivity scale factor
Self-test
2. Accelerometer Features
The triple-axis MEMS accelerometer in MPU-9250 includes a wide range of features:
Digital-output triple-axis accelerometer with a programmable full scale range of ±2g, ±4g, ±8g and ±16g and integrated 16-bit ADCs
Accelerometer normal operating current: 450µA
Low power accelerometer mode current: 8.4µA at 0.98Hz, 19.8µA at 31.25Hz
Sleep mode current: 8µA
User-programmable interrupts
Wake-on-motion interrupt for low power operation of applications processor
Self-test
3.Magnetometer Features
The triple-axis MEMS magnetometer in MPU-9250 includes a wide range of features:
3-axis silicon monolithic Hall-effect magnetic sensor with magnetic concentrator
Wide dynamic measurement range and high resolution with lower current consumption.
Output data resolution of 14 bit (0.6µT/LSB)
Full scale measurement range is ±4800µT
Magnetometer normal operating current: 280µA at 8Hz repetition rate
Self-test function with internal magnetic source to confirm magnetic sensor operation on end products
1.Gyroscope Features
The triple-axis MEMS gyroscope in the MPU-9250 includes a wide range of features:
Digital-output X-, Y-, and Z-Axis angular rate sensors (gyroscopes) with a user-programmable fullscale range of ±250, ±500, ±1000, and ±2000°/sec and integrated 16-bit ADCs
Digitally-programmable low-pass filter
Gyroscope operating current: 3.2mA
Sleep mode current: 8µA
Factory calibrated sensitivity scale factor
Self-test
2. Accelerometer Features
The triple-axis MEMS accelerometer in MPU-9250 includes a wide range of features:
Digital-output triple-axis accelerometer with a programmable full scale range of ±2g, ±4g, ±8g and ±16g and integrated 16-bit ADCs
Accelerometer normal operating current: 450µA
Low power accelerometer mode current: 8.4µA at 0.98Hz, 19.8µA at 31.25Hz
Sleep mode current: 8µA
User-programmable interrupts
Wake-on-motion interrupt for low power operation of applications processor
Self-test
3.Magnetometer Features
The triple-axis MEMS magnetometer in MPU-9250 includes a wide range of features:
3-axis silicon monolithic Hall-effect magnetic sensor with magnetic concentrator
Wide dynamic measurement range and high resolution with lower current consumption.
Output data resolution of 14 bit (0.6µT/LSB)
Full scale measurement range is ±4800µT
Magnetometer normal operating current: 280µA at 8Hz repetition rate
Self-test function with internal magnetic source to confirm magnetic sensor operation on end products
